Festool Hole drilling set LR 32 Set

Hole series are always drilled with a spacing of 32 mm and a hole diameter of 5 mm or 3 mm. The hole series drilling system is a set for fast and simple production of series of holes for shelf supports, rear wall supports and fittings with the OF 1010 or OF 1400 router.

Strengths and benefits

• With the LR 32 system – comprising the guide rail FS 1400/2-LR 32 or FS 2424/2-LR 32 and the hole drilling system – precise rows of holes spaced 32 mm apart can be drilled with the Festool router
• The LR 32 guide rail is aligned quickly and parallel to the two side stops, which are positioned by means of an adjustable stop at the workpiece and guide rail
• The guide rail is precisely positioned with 9.5, 16 or 32 mm edge clearance over the stopper in the longitudinal direction
• Centring mandrel for perfect centring of the router on the guide plate
• Spring-loaded positioning rocker for effective operation when drilling the hole series
• Perfectly guided through fine adjustment of the guide play and additional handle on the guide plate

Main areas of use

• Preparing holes series with 32 mm spacing
• Drilling of fittings like cupboard hinges

Notes

• for use with hole line guide rails

Compatible with

for routers OF 900, OF 1000, OF 1010, OF 1400 in the FS-LR32 hole drilling system

Scope of delivery

guide plate, centring mandrel, 2 parallel side fences with adjustable stop, 2 x Longitudinal stop
