Festool Hole drilling set LR 32-SYS

Hole series are always drilled with a spacing of 32 mm and a hole diameter of 5 mm or 3 mm. The hole series drilling system is a complete set for fast and simple production of series of holes for shelf supports, rear wall supports and fittings with the OF 1010 or OF 1400 router. Everything in a single Systainer.

Strengths and benefits

• Everything that you need for a series of holes at hand in one Systainer
• With the LR 32 system – comprising the guide rail FS 1400/2-LR 32 or FS 2424/2-LR 32 and the hole drilling system – precise rows of holes spaced 32 mm apart can be drilled with the Festool router
• The LR 32 guide rail is aligned quickly and parallel to the two side stops, which are positioned by means of an adjustable stop at the workpiece and guide rail
• The guide rail is precisely positioned with 9, 5, 16 or 32 mm edge clearance over the stopper in the longitudinal direction
• Centring mandrel for perfect centring of the router on the guide plate
• Spring-loaded positioning rocker for effective operation when drilling the hole series
• Perfectly guided through fine adjustment of the guide play and additional handle on the guide plate
• Properly secured thanks to the supplied guide rail clamps
• The most important hinge location cutters are already included in the set

Main areas of use

• Preparing holes series with 32 mm spacing
• Drilling of fittings like cupboard hinges

Product details

Everything included

Everything in one Systainer: Guide plate, centring mandrel, operating tool, HW hinge location cutter with 35 mm diameter, HW dowel drill with 5 mm diameter (V-shaped tip), HW dowel drill with 5 mm diameter (with centre point and pre-cutter), two parallel side fences with adjustable stop, fastening clamp and two longitudinal stops.

Customised vehicle integration

Thanks to the special holder, Systainer³ can be directly integrated into bott vario3 vehicle equipment.

Ergonomic transportation

The front carrying handle allows for ergonomic carrying close to the body.

Open, close, connect with a single turn

All Systainer³ can be connected to one another and to other generations. The content is accessible at all times, without having to disconnect them first.

A tidy storage system

Systainer³ units can be connected to many other system accessories, e.g. mobile dust extractors.

All-round protection

Everything is effectively protected against dust, spray water or changes in temperature in the Systainer³.

Content security

Thanks to the integrated latch, the content of the Systainer³ can be locked securely.

Notes

• for use with hole line guide rails

Compatible with

for OF 900, OF 1000, OF 1010, OF 1010 R, OF 1400 in the FS-LR 32 hole drilling system

Scope of delivery

guide plate, centring mandrel, hinge location cutter HM Ø 35 mm, dowel drill HW Ø 5 mm (V-shaped tip), dowel drill HM Ø 5 mm (with centring bit and pre-cutter), 2 parallel side fences with adjustable stop, FSZ 120 fastening clamps (two units), Longitudinal stop, screwdriver, WAF 5, Systainer SYS3 M 112

Technical data
