Festool Cross anchor SV-QA D14/32

The DOMINO connectors: Create perfect wooden joints more quickly and easily than ever before. With the corner and surface connectors for the DOMINO XL DF 700 joining machine, we’ve taken the DOMINO concept to the next level in a revolutionary way. Designed for frames, racks, and panel joints that don’t just stand out for their outstanding precision and stability, but also for their incredible flexibility and unmatched efficiency.

Strengths and benefits

• The SV-QA D14 cross anchor combines with the SV-AB D14 anchor bolt and the SV-SA D14 split anchor to form the corner connector, or combines with the SV-DB D14 double-headed bolt and optionally with the SV-V D14 widener to form the flat connector. All parts are available either in the DOMINO SV-SYS D14 DOMINOVerb connection Systainer, as an EV/32 set, as an FV/16 set or individually as individual parts
• The corner and flat connector system for the DOMINO XL DF 700 joining machine enables stable connections that can be separated again at a material thickness of 30 mm or higher
• For frame and rack joints (corner connectors) and board connections (flat connectors) that will impress you with extreme precision and stability as well as maximum flexibility and unique efficiency
• Extremely quick thanks to simple milling using machine stops or pencil markings. No template or other accessories required
• Extremely stable with dowel and clamping element for strong connections. High pulling and tightening distance. Extremely high pull-out and load forces
• Extremely flexible and can be detached again quickly if necessary
• With cover caps in three colours for a high-quality corner connection appearance

Main areas of use

• For furniture designs that can be dismantled such as beds, tables, etc.
• For creating detachable flat connections for furniture manufacturing such as kitchen worktops, benches, etc.

Product details

The 14x75mm dowels are spot on for the corner and flat connector system with the DOMINO XL DF 700 joining machine, meaning you don’t have to faff about switching between dowel routing and connector routing.

Corner connector: Not only extremely quick and extremely stable, but also boasting a high-quality appearance: The only visible part is the cover cap, which is clipped over the oval milled holes that are typical to DOMINO. Flat connector: Large clamping distance for secure locking and a strong, stable connection.

Modular components

The SV-QA D14 cross anchor combines with the SV-AB D14 anchor bolt and the SV-SA D14 split anchor to form the corner connector, or combines with the SV-DB D14 double-headed bolt and optionally with the SV-V D14 widener to form the flat connector. All parts are available either in the DOMINO SV-SYS D14 DOMINOVerb connection Systainer, as an EV/32 set, as an FV/16 set or individually as individual parts.

Stable and detachable

The corner and flat connector system for the DOMINO XL DF 700 joining machine enables stable connections that can be separated again at a material thickness of 30 mm or higher.

Connect quickly, and release if necessary

For frame and rack joints (corner connectors) and board connections (flat connectors) that will impress you with extreme precision and stability as well as maximum flexibility and unique efficiency.

Extremely quick

Via simple milling using machine stops or pencil markings. No template or other accessories required.

Extremely stable

Dowel and clamping element for a strong connection. Extremely high pull-out and load forces.

Extremely flexible

Connection can be detached again quickly if necessary. For frame and rack joints (corner connectors) and board connections (flat connectors) at material thicknesses of 30 mm or higher.

Notes

• includes set screws
• for processing using the DOMINO XL DF 700 joining machine
• at a material thickness of 30 mm or higher
• acts as a counter bearing and tightening element for anchor bolts or double-headed bolts
• with soft or porous material such as chipboard, the use of the cross anchor expander SV-V D14 is recommended (for material thickness 35 mm and greater – stops the cross anchor being pulled into the material)
• in conjunction with SV-SA D14 split anchors and SV-AB D14 anchor bolts for creating corner connections
• in conjunction with SV-DB D14 double-headed bolts for creating flat connections

Compatible with

for DF 700
